EuroMag 4 Inch Digital Electromagnetic Water Flow Meter (Euromag-FM-100S) BD

EuroMag 4 Inch Digital Electromagnetic Water Flow Meter (Euromag-FM-100S) are the best solution to measure conductive liquids with minimum conductivity of 5μS/cm, as they offer rapid response time, high measuring accuracy and long term stability. No moving parts in the pipe and no obstruction to the liquid, with great advantage of no-pressure loss and virtually maintenance free system. Our electromagnetic flowmeters cover a wide range of applications and satisfy every customer demand: flanged, wafer, threaded and insertions DN100 with pressure class up to ANSI900.

A 4-inch digital electromagnetic water flow meter is a specialized device designed for accurately measuring the flow of water and other conductive fluids through pipelines with a 4-inch (approximately 100 mm) diameter. These meters use the principles of electromagnetic induction to deliver precise, reliable measurements, making them ideal for various industrial, agricultural, and municipal applications.

The 4-inch digital electromagnetic water flow meter is a highly reliable and efficient solution for measuring the flow of conductive fluids. Its advanced features, robust construction, and versatility make it an essential tool in various sectors. Whether managing water resources or optimizing industrial processes, this device offers unmatched precision and durability.

Advantage of 4 Inch Digital Electromagnetic Water Flow Meter

Electromagnetic Technology
The meter operates based on Faraday’s Law of Electromagnetic Induction. When a conductive fluid flows through a magnetic field generated by the meter, a voltage is induced. This voltage is directly proportional to the velocity of the fluid, allowing for accurate flow measurement.

Digital Interface
Equipped with a digital display, the EuroMag 4 Inch Digital Electromagnetic Water Flow Meter (Euromag-FM-100S) provides real-time data on flow rate, cumulative volume, and other relevant metrics. Many models also include communication options like Modbus, RS485, or wireless protocols for integration into advanced control systems.

High Accuracy
These meters offer high accuracy, typically within ±0.5% of the actual flow rate, making them suitable for applications where precision is critical, such as chemical dosing, water distribution, and wastewater management.

No Moving Parts
With no moving mechanical components, electromagnetic flow meters are virtually maintenance-free and resistant to wear and tear, ensuring long-term durability.

Wide Range of Fluid Compatibility

The meter is suitable for a variety of conductive fluids, including potable water, wastewater, slurries, and other industrial liquids. Non-conductive fluids, like oils or deionized water, cannot be measured using this technology.

Corrosion-Resistant Construction
These meters are typically made from materials such as stainless steel, PTFE (polytetrafluoroethylene), or other corrosion-resistant linings, making them ideal for aggressive chemical environments.

Applications

Water Treatment Plants
Used to monitor and control water flow in filtration and distribution systems.

Irrigation Systems
Essential for measuring water usage in agricultural irrigation networks to optimize water consumption.

Industrial Processes
Applied in industries for monitoring cooling water, chemical mixing, and process control.

Municipal Water Distribution
Ensures accurate billing and efficient management of water supply networks.

Wastewater Management
Ideal for measuring and monitoring sewage or wastewater flows due to its non-intrusive design.

FEATURES OF EUROMAG 4 INCH DIGITAL ELECTROMAGNETIC WATER FLOW METER (EUROMAG-FM-100S)

• Flow tube Material AISI 304, AISI 316 (optional).
• Flanges Material Carbon steel (S235JR – 1.0037), AISI 304 optional, AISI 316 optional.
• Available electrodes AISI316 (standard), Hastelloy C, Hastelloy B, Titanium, Tantalum, Platinum.
• Internal lining Ebonite.
• Liquid Temperature -40°C / + 80°C.
• Available Diameters 4” inches(100mm).
• Standard flanged connection EN1092-1 PN 16, ANSI 150.
• Flanged Connection on request AS 2129 (Table D, E, F), AS 4087 (PN 16, 21), KS10K, others on request.
• Standard Operation Pressure 21 Bar.
• Pressure Drop Class DN≤80 ΔP10 (< 0,10 bar) and DN≥100 ΔP16 (< 0,16 bar).
• Installation requirements/condition U0-D0.
• Protection Degree IP68 permanent submersion at 1,5 m (EN 60529).
• Converters Compatibility MC608A/B/R/P, MC406.
• Electrical Connections Cable glands M20 x 1.5 + terminal box + sealing resin.

SPECIFICATION OF EUROMAG 4 INCH DIGITAL ELECTROMAGNETIC WATER FLOW METER (EUROMAG-FM-100S)

Name	Details
Model	Euromag-FM-100S
Brand	EuroMag
Origin	Italy
Flow tube Material	AISI 304, AISI 316 (optional).
Flanges Material	Carbon steel (S235JR – 1.0037), AISI 304 optional, AISI 316 optional.
Available electrodes	AISI316 (standard), Hastelloy C, Hastelloy B, Titanium, Tantalum, Platinum.
Internal lining	Ebonite.
Liquid Temperature	-40°C / + 80°C.
Available Diameters	4” inches(100mm).
Standard flanged connection	EN1092-1 PN 16, ANSI 150.
Flanged Connection on request	AS 2129 (Table D, E, F), AS 4087 (PN 16, 21), KS10K, others on request.
Standard Operation Pressure	21 Bar.
Pressure Drop Class	DN≤80 ΔP10 (< 0,10 bar) and DN≥100 ΔP16 (< 0,16 bar).
Installation requirements/condition	U0-D0.
Protection Degree	IP68 permanent submersion at 1,5 m (EN 60529).
Converters Compatibility	MC608A/B/R/P, MC406.
Electrical Connections	Cable glands M20 x 1.5 + terminal box + sealing resin.
