SUJA GLOBAL 3 Ton Electric Wire Rope Hoist with trolley SGRH-3T is a type of material handling equipment, installed on a single beam crane, linear curve strander beams or it can be used at the hoisting mechanism of double beam crane, gantry crane, linear crane for material handling by industrial and mining enterprises, railways, and warehouses, etc. The lifting capacity of single speed electric wire rope hoist is 3 ton and the working class is M3.

This is single speed, electric hoist. Wire rope electric hoist is the most common lifting equipment, which can be installed on single girder overhead crane or single beam gantry crane. With different design principles and using environments, small electric hoist remote control have two kinds of type, which is traveling hoist and stationary hoist. Generally speaking, electric hoist has pendent control and wireless control.



FEATURES

  • Lifting Capacity: 3 TON
  • Lifting Height: 8 Metre
  • Running Speed: 20/30 (m/min)
  • Wire Rope Type: 6×37+1
  • Wire Rope Dia: 12mm
  • I-Beam Track Model: 16-28b
  • Working Duty: M3
  • Lifting Height Power: 4.5 KW
  • Lifting Height R.P.M: 1380
  • Lifting Height Power supply: 440v 50/60hz 3phase
  • Running Motor Power: 0.4 KW
  • Running Motor R.P.M: 1380
  • Running Motor Power supply: 440v 50/60hz 3phase
  • Weight: 353 kg
  • Certification: CE, ISO



SPECIFICATION

Name Details
Model SGRH-3T
Brand SUJA GLOBAL
Origin Singapore
Lifting Capacity (T) 3 TON
Lifting Height (m) 9 Meter
Lifting Speed (m/min) 8
Running Speed (m/min) 20/30
Wire Rope Type

Wire Rope Data

 6×37+1

12mm
I-Beam Track Model 16-28b
Working Duty M3
Lifting Height Power(kw) 4.5
Lifting Height R.P.M(r/min) 1380
Lifting Height Power supply 220-440v 50/60hz 3phase
Running Motor Power (kw) 0.4
Running Motor R.P.M(r/min) 1380
Running Motor Power supply 220-440v 50/60hz 3phase
Weight 353 kg
Certification CE, ISO
