SM-842 Wood Building Material Moisture Meter in Bangladesh 2024

SUJA GLOBAL

A wood moisture meter is a useful tool for measuring the moisture content of wood and other building materials. It can help determine whether the wood is dry enough for use in construction or if it needs further drying to prevent issues such as warping, cracking, or mold growth.

Basically , there are various types of wood moisture meters available in the market. One common type is a pinless moisture meter, which uses electromagnetic waves to measure the moisture content of the wood without damaging it. Another type is a pin-type moisture meter, which uses two metal pins that are inserted into the wood to measure its moisture levels.

When using a wood moisture meter, it is important to follow the manufacturer’s instructions for accurate readings. It is also recommended to test multiple areas of the wood to get a representative measurement. Besides, the moisture content of wood is typically expressed in percentages, and the acceptable range varies depending on the specific application or use of the wood.

Remember that moisture meters are not only designed specifically for wood but are also the most accurate for measuring the moisture content of wood building materials. Other types of moisture meters may have different ranges suitable for measuring moisture in materials other than wood.





Features

• Use on wood, bamboo, paper, wood fiber articles, and building materials
• Big LCD with backlight
• Replaceable electrode pins
• 2-in-1 Digital LCD readout and analog bar graph
• Simultaneous measurement and display of moisture & temperature readings
• Materials selection measurements > MAX/MIN/DATA Hold
• Auto power off





Technical Specifications

Model: SM-842

Brand: SUJA GLOBAL

Origin: Singapore

Electrode length: 10mm (replaceable)

Moisture Range: Wood: 5-70%RH / Building materials: 0.1-2.4% RH

Temp. Range: -20-70°C/-4-158°F

Moisture Accuracy: Wood: 5-30%: ±1%, 30-60%: +2%, 60-70%: +4%, other materials: ±0.5%

Temp. Accuracy: -20-70°C/-4-158 F: +1.5°C/2.7°F

Auto Power Off: Meter shuts off automatically after 120 seconds of inactivity

Power Supply: One 9V battery

Operating Temp.: 0-50°C/32-122°F

Operating Humidity: 0-85%RH

Size: (163 x 62 x 30)mm

Weight: 153g(with battery)







CLICK HERE TO DOWNLOAD THE USER MANUAL OF SM-842 WOOD BUILDING MATERIAL MOISTURE METER PDF
